| Form Factor (Midi, Micro, Mini ITX, Full) | Midi | |
| Chassis | SPCC :0.45mm | |
| PSU Form Factor | Bottom/ATX | |
| M/B Form Factor | ATX、M-ATX、ITX | |
| Front Panel | ABS | |
| Top Panel | metal cover | |
| Branding | Box | |
| Unit | ||
| (Unit) Position | ||
| Side Panel | Left | Tempered Glass |
| Right | metal cover | |
| External Drive Bay(s) | 5.25" (ODD) | *0 |
| 3.5" | *0 | |
| Internal Drive Bay(s) | 3.5" (HDD) | *2 |
| 2.5" (SSD) | *2 | |
| 1*3.5HDD+3*2.5SSD or 2*3.5HDD+2*2.5SSD | ||
| I/O | Buttons | *2 |
| USB1.1 Port(s) | *0 | |
| USB2.0 Port(s) | *2 | |
| USB3.0 Port(s) | *1( optional) | |
| USB3.1 Port(s) | *0 | |
| HD Audio Support | *1 | |
| Card Reader (Support) | *0 | |
| P-Lock | *0 | |
| RGB Controller | *0 | |
| Controller max. fans | *0 | |
| RGB Controller max. LED strips | *0 | |
| Remote (IR or RF) | *0 | |
| Cooling Fan Support | Front | 3x120mm,2x140mm(Fan optional) |
| Top | 2x120mm ,2x140mm (Fan optional) | |
| Rear | 1x120mm (Fan optional) | |
| Left Side | 0 | |
| PSU Cover | 0 | |
| Water Cooling Support (Radiator Size) | Front | 120mm, 140mm,240mm,280mm |
| Top | 120mm, 140mm,240mm | |
| Rear | 120mm*1 | |
| Dust Cover | Bottom and top cover with dust filter | |
| Slots | *7 | |
| Carton & Logo | GAMEMAX | |
| Dimensions | Chassis | (L)360*(W)210*(H)440mm |
| Full Case (inc Fascia) | (L)408*(W)210*(H)460mm | |
| Carton | (L)506*(W)266*(H)465mm | |
| Net Weight (Kg) | kgs | |
| Gross Weight (Kg) | kgs | |
| VGA Card Length | up to 340mm | |
| CPU Cooler Height | 164mm | |
| Cable Management Depth | 22mm | |
